Description
This industrial Ethernet adapter by Delock can be used to connect various components with M12 connectors, e.g. for machine control or automation.
Round built-in version – angled design
The round built-in version of the M12 adapter enables space-saving and secure integration directly into switch panels, housings or connection panels. The angled design is ideal for tight installation situations and ensures clean, structured cable routing in industrial applications.
Specification
• Connectors:
1 x M12 male D-coded 4 pin
1 x RJ45 jack 90° angled
• Cat.5e specification
• Shielded
• Round built-in version
• Angled design
• Installation dimensions: 16.3 x 13.8 mm
• Silicone sealing ring blue
• Housing material: PE
• M16 x 1.5 mm external thread
• Operating voltage: max. 250 V
• Current: max. 4 A
• Operating temperature: -25 °C ~ 85 °C
• Protection class: IP67 (M12)
• Colour: black
• Dimensions (LxD): ca. 44.0 x 24.5 mm
System requirements
Package content
• Adapter
This industrial Ethernet adapter by Delock can be used to connect various components with M12 connectors, e.g. for machine control or automation.
Round built-in version – angled design
The round built-in version of the M12 adapter enables space-saving and secure integration directly into switch panels, housings or connection panels. The angled design is ideal for tight installation situations and ensures clean, structured cable routing in industrial applications.
Specification
• Connectors:
1 x M12 male D-coded 4 pin
1 x RJ45 jack 90° angled
• Cat.5e specification
• Shielded
• Round built-in version
• Angled design
• Installation dimensions: 16.3 x 13.8 mm
• Silicone sealing ring blue
• Housing material: PE
• M16 x 1.5 mm external thread
• Operating voltage: max. 250 V
• Current: max. 4 A
• Operating temperature: -25 °C ~ 85 °C
• Protection class: IP67 (M12)
• Colour: black
• Dimensions (LxD): ca. 44.0 x 24.5 mm
System requirements
Package content
• Adapter
4043619906642
