Delock USB 2.0 Camera Module 1.92 mega pixel 45° edge fix focus

Description
The USB 2.0 camera module by Delock offers a very compact design, high resolution and low power consumption.
It is ideally suited for integration into devices.
The use of a photosensitive sensor with back side illumination (BSI) expands the scope of this module.

Specification
• Connector: 5 pin SMT plug, 1 mm pitch (ACES 87214-0500), USB 2.0 high speed
• Resolution: 1.92 Mega Pixel
• With optical IR filter
• Supports resolutions: 720 p (1280 x 720)
• Different fully-automated shutter priority:
  - Automatic exposure control (AEC)
  - Automatic white balance (AWB)
  - Automatic band filter (ABF)
  - Automatic black level calibration (ABLC)
• Image quality controls including colour saturation, gamma, sharpness,
  lens correction, white pixel cancelling,
  noise cancelling, and automatic 50/60 Hz luminance detection
• Supports scaling
• Power consumption:
  Suspend: 9 mA
  Active: 100 mA ± 10 mA @ 720p
• Operating voltage: 5 V
• Operating temperature: 0 °C ~ 50 °C
• Lense dimension: 1/4 "
• Fix focus: 0.3 m ~ infinity
• Lense: F/2.5
• Frame rates: 30fps @ HVGA, VGA, XGA, 720p, QVGA
• Dimension (LxWxH): 60.0 x 8.0 x 6.3 mm

System requirements
• Windows Vista 7/8/10
• MS DirectX 9.0c and above
• Linux 2.6.15 and above with Video4Linux
• CPU minimum P4 1.4 GHz, 128 MB RAM

Package content
• Camera module
