This 15" small monitor is perfect for Point Of Sale systems with the included stand and the IP54 rated water resistant front face.  The stand can also be removed for use with any VESA mounts making it perfect for home automation purposes or any mounting situation

Applications:

  • Transportation: Naval, Avionics, Heavy Vehicles, Onboard Computer, Public Transportation
  • Integration: Machine Control, Industrial Automation, Environmental Monitoring, Home Automation, Home Automation
  • Selling Points: Receptions, Digital Signage, Self-Service Stations, Outdoor Totems

Specification:

  • Screen Size: Diagonal 15"
  • Physical Resolution: 1024 (H) x 768 (V) XGA
  • Supported Resolution: 640 x 480 ~ 1024 x 768
  • Dot Resolution: 3072 x 768 = 2,359,296 (dots)
  • Brightness: 300 cd/m²
  • Contrast Ratio: 800:1
  • Viewing Angle: 160° Horizontal, 160° Vertical
  • Response Time: 8ms (Typ.)
  • Power Supply: DC 12V
  • Power Consumption: 18W
  • Operating Temperature: 32°F ~ 104°F
  • Storage Temperature: 14°F ~ 122°F
  • MTBF (Mean Time Between Failures): > 55,000 Hours or > 6.2 Years of continuous operation
  • Dimension w/o base (mm): 360.6W x 290.5H x 34.9D
  • Weight (kg): 3,4 w/ base / 2,3 w/o base
  • IP54 Spill and Dust Proof Rimless Front Bezel
  • 300NIT Long Life LED Backlight
  • 5-Wire Resistive Touchscreen
  • Anti-Glare Coating
  • Multi-Monitor Touchscreen Support
  • HDMI Input x 1 (HDCP), VGA Input (15 pin D-SUB) x 1
  • 1024x768 Native Resolution, 4x3 Aspect Ratio
  • Solid Capacitors for Improved Durability
  • High Performance Image and Video Signal Processor
  • AISS - Advanced Image-Scaling and Shaping
  • Last Input and Power Setting Memory
  • Auto Power-On upon signal detection
  • Function to Disable Front Buttons
  • Removable Stand
  • VESA 75mm Mounting Holes
  • Supports 12V DC
  • FCC, CE Certification
  • ROHS Compliant
