Applications:
- Transportation: Naval, Avionics, Heavy Vehicles, Onboard Computer, Public Transportation
- Integration: Machine Control, Industrial Automation, Environmental Monitoring, Home Automation, Home Automation
- Selling Points: Receptions, Digital Signage, Self-Service Stations, Outdoor Totems
- Sunlight Readable – Ready for all environments
- Waterproof/Dustproof– Built to Stringent IP69K and IP66 Standards
- Multiple Inputs – HDMI, DVI, and VGA Inputs
- Automatic Dimming – Built in Ambient Light Sensor
- Superior Image – Scalable resolution up to 1080P
- Extended Temperature Range
Specification:
- Screen Size: Diagonal 24" (16:9)
- Physical Resolution: 1920 (H) x 1080 (V) HD
- Supported Resolution: 640 x 480 ~ 1920 x 1080
- Brightness: 1000 cd/m²
- Contrast Ratio: 5000:1
- Viewing Angle: 178° Horizontal, 178° Vertical
- Response Time (Tr+Tf): 25ms (Typ.)
- Touch Screen Interface: USB port
- Operating Voltage Range: DC 12V
- Power Supply: DC 12V
- Power Consumption: ≤ 45W
- Operating Temperature: -22°F ~ 158°F (-30°C ~ 70°C)
- Storage Temperature: -22°F ~ 167°F (-30°C ~ 75°C)
- Vibration: Operating Random Vibration Test (5-500Hz, 1.0Grms), IEC 60068-2-64 standard
- Shock: Operating Shock Test, 10G peak acceleration (11ms duration), IEC 60068-2-27 standard
- MTBF (Mean Time Between Failures): > 55,000 Hours or > 6.2 Years of continuous operation
- Dimension (mm): 608W x 392H x 54D
- Weight (kg): 10,2
- IP69K High Temperature High Pressure Spray Down Protection
- IP66 / NEMA4X Rated Water and Dust Resistance
- 1,000NIT Sunlight Readable with Long Life LED Backlight
- Wide Viewing Angle IPS (In-Plane Switching) LCD Panel
- Automatic Backlight Adjustment through Built-in Ambient Light Sensor
- Projected Capacitive Multi-Touch Touchscreen (USB)
- Plug-N-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS)
- Multi-Monitor Touchscreen Support
- HDMI Input x 1 (HDCP), VGA Input (15 pin D-SUB)
- 1920x1080 Native Resolution, 16x9 Aspect Ratio
- High Performance Image and Video Signal Processor
- AISS - Advanced Image-Scaling and Shaping
- Last Input and Power Setting Memory
- Auto Power-On upon signal detection
- VESA 100mm and 200mm x 100mm Mounting Holes
- Heavy-Duty IP67 Waterproof Connectors
- Ruggedized Stainless-Steel Casing
- FCC, CE Certification
- ROHS Compliant
Package Contents
- 5M Waterproof HDMI Cable with IP67 connector
- 5M Waterproof VGA Cable with IP67 M12 SUS316 stainless steel connector
- 5M Waterproof USB Cable with IP67 M12 SUS316 stainless steel connector
- 5M Waterproof Power Cable with IP67 M12 SUS316 stainless steel connector
